Seeing that I do lots of migrations throughout the course of my job, its always good to explore some of the newer features so that you are familiar with them and feel good about putting them into your tool-bag for future use. One of the things that I could see being useful is the ability to migrate a single PDB from one platform to the other. Upon researching the possibilities, I found that migrating and converting the endianness of a PDB really wasn’t documented. What was documented was a process to migrate a PDB from one platform to another when endianness is the same between platforms.
Given that, I wanted to see if the process for converting an entire container using transportable tablespaces could be applied to a single PDB. Unfortunately there is downtime required, but here is what I found:
Create Backup of Source PDB
Determine for a given user what tablespaces are impacted, check for any violations which may occur due to transport, set those tablespaces to read-only and then invoke RMAN by connecting to the PDB and take a backup:
SQL> select * from v$transportable_platform;
PLATFORM_ID PLATFORM_NAME ENDIAN_FORMAT CON_ID
----------- ---------------------------------------- -------------- ----------
2 Solaris[tm] OE (64-bit) Big 0
SQL> exec SYS.DBMS_TTS.TRANSPORT_SET_CHECK(ts_list => 'HR_TEST', incl_constraints => TRUE);
PL/SQL procedure successfully completed.
SQL> SELECT * FROM transport_set_violations;
no rows selected
export NLS_DATE_FORMAT='DD-MON-YY HH24:MI:SS'
rman target sys@xttpdb
RMAN> alter tablespace hr_test read only;
using target database control file instead of recovery catalog
Statement processed
RMAN> alter tablespace users read only;
Statement processed
RUN
{
ALLOCATE CHANNEL XPLATFORM_BKUP_DISK1 DEVICE TYPE DISK;
ALLOCATE CHANNEL XPLATFORM_BKUP_DISK2 DEVICE TYPE DISK;
BACKUP TO PLATFORM 'Linux x86 64-bit' AS COMPRESSED BACKUPSET FILESPERSET 1
FORMAT '/export/home/oracle/backups/%d_xplat_bs%s_piece%p_%T_%U.bkp'
DATAPUMP FORMAT '/export/home/oracle/backups/transport_tblsp_hr_test_meta.dmp'
TABLESPACE HR_TEST, USERS;
RELEASE CHANNEL XPLATFORM_BKUP_DISK1;
RELEASE CHANNEL XPLATFORM_BKUP_DISK2;
}
allocated channel: XPLATFORM_BKUP_DISK1
channel XPLATFORM_BKUP_DISK1: SID=752 instance=xttsun1 device type=DISK
allocated channel: XPLATFORM_BKUP_DISK2
channel XPLATFORM_BKUP_DISK2: SID=745 instance=xttsun1 device type=DISK
Starting backup at 29-OCT-20
Running TRANSPORT_SET_CHECK on specified tablespaces
TRANSPORT_SET_CHECK completed successfully
Performing export of metadata for specified tablespaces...
EXPDP> Starting "SYS"."TRANSPORT_EXP_XTTSUN_aahC":
EXPDP> Processing object type TRANSPORTABLE_EXPORT/INDEX_STATISTICS
EXPDP> Processing object type TRANSPORTABLE_EXPORT/TABLE_STATISTICS
EXPDP> Processing object type TRANSPORTABLE_EXPORT/STATISTICS/MARKER
EXPDP> Processing object type TRANSPORTABLE_EXPORT/PLUGTS_BLK
EXPDP> Processing object type TRANSPORTABLE_EXPORT/POST_INSTANCE/PLUGTS_BLK
EXPDP> Processing object type TRANSPORTABLE_EXPORT/TABLE
EXPDP> Processing object type TRANSPORTABLE_EXPORT/INDEX/INDEX
EXPDP> Processing object type TRANSPORTABLE_EXPORT/CONSTRAINT/CONSTRAINT
EXPDP> Processing object type TRANSPORTABLE_EXPORT/COMMENT
EXPDP> Processing object type TRANSPORTABLE_EXPORT/CONSTRAINT/REF_CONSTRAINT
EXPDP> Processing object type TRANSPORTABLE_EXPORT/TRIGGER
EXPDP> Master table "SYS"."TRANSPORT_EXP_XTTSUN_aahC" successfully loaded/unloaded
EXPDP> ******************************************************************************
EXPDP> Dump file set for SYS.TRANSPORT_EXP_XTTSUN_aahC is:
EXPDP> /u01/app/oracle/product/12.2.0/dbhome_1/dbs/backup_tts_XTTSUN_66977.dmp
EXPDP> ******************************************************************************
EXPDP> Datafiles required for transportable tablespace HR_TEST:
EXPDP> +DATAC1/XTTSUN/B2A8DA5A8E2A777EE0540010E05D13EA/DATAFILE/hr_test.302.1054902701
EXPDP> Datafiles required for transportable tablespace USERS:
EXPDP> +DATAC1/XTTSUN/B2A8DA5A8E2A777EE0540010E05D13EA/DATAFILE/users.435.1054891719
EXPDP> Job "SYS"."TRANSPORT_EXP_XTTSUN_aahC" successfully completed at Thu Oct 29 13:14:42 2020 elapsed 0 00:02:17
Export completed
channel XPLATFORM_BKUP_DISK1: starting compressed full datafile backup set
channel XPLATFORM_BKUP_DISK1: specifying datafile(s) in backup set
input datafile file number=00018 name=+DATAC1/XTTSUN/B2A8DA5A8E2A777EE0540010E05D13EA/DATAFILE/hr_test.302.1054902701
channel XPLATFORM_BKUP_DISK1: starting piece 1 at 29-OCT-20
channel XPLATFORM_BKUP_DISK2: starting compressed full datafile backup set
channel XPLATFORM_BKUP_DISK2: specifying datafile(s) in backup set
input datafile file number=00017 name=+DATAC1/XTTSUN/B2A8DA5A8E2A777EE0540010E05D13EA/DATAFILE/users.435.1054891719
channel XPLATFORM_BKUP_DISK2: starting piece 1 at 29-OCT-20
channel XPLATFORM_BKUP_DISK2: finished piece 1 at 29-OCT-20
piece handle=/export/home/oracle/backups/XTTSUN_xplat_bs36_piece1_20201029_14ve6dm4_1_1.bkp tag=TAG20201029T131156 comment=NONE
channel XPLATFORM_BKUP_DISK2: backup set complete, elapsed time: 00:00:03
channel XPLATFORM_BKUP_DISK1: finished piece 1 at 29-OCT-20
piece handle=/export/home/oracle/backups/XTTSUN_xplat_bs35_piece1_20201029_13ve6dm4_1_1.bkp tag=TAG20201029T131156 comment=NONE
channel XPLATFORM_BKUP_DISK1: backup set complete, elapsed time: 00:00:35
channel XPLATFORM_BKUP_DISK1: starting compressed full datafile backup set
input Data Pump dump file=/u01/app/oracle/product/12.2.0/dbhome_1/dbs/backup_tts_XTTSUN_66977.dmp
channel XPLATFORM_BKUP_DISK1: starting piece 1 at 29-OCT-20
channel XPLATFORM_BKUP_DISK1: finished piece 1 at 29-OCT-20
piece handle=/export/home/oracle/backups/transport_tblsp_hr_test_meta.dmp tag=TAG20201029T131156 comment=NONE
channel XPLATFORM_BKUP_DISK1: backup set complete, elapsed time: 00:00:01
Finished backup at 29-OCT-20
released channel: XPLATFORM_BKUP_DISK1
released channel: XPLATFORM_BKUP_DISK2
RMAN> exit
Copy Backup Files and Metadata File to New Platform
Using normal methods such as scp, copy the files generated by RMAN to the new platform. One caveat, is that until 19c, the data pump file for the metadata is copied to $ORACLE_HOME/dbs so you must make sure that you have sufficient space there for the process to complete successfully.
Restore / Convert Endian on New Platform
The last step in the process is the setup of the new PDB, creation of the user in the PDB and then use RMAN to transport the table spaces. The general process can be done simply by executing the following steps:
- Create empty pluggable database and create target user in the new PDB:
SQL> select * from v$transportable_platform;
PLATFORM_ID PLATFORM_NAME ENDIAN_FORMAT CON_ID
----------- ---------------------------------------- -------------- ----------
13 Linux x86 64-bit Little 0
SQL> CREATE PLUGGABLE DATABASE xttpdb ADMIN USER pdb_admin IDENTIFIED BY Welcome123 CREATE_FILE_DEST='+DATA';
Pluggable database created.
SQL> CREATE USER "HR" IDENTIFIED BY VALUES 'S:904B950378D93630E729A1A3051796718B7511BA10F5273F2F031E5CF76D;T:22D35135BC49EEAF5F4C896F26E2E8802D869C6451F39241BB4ACB76A38B7396E1C516DC78F0AFB1D3A96ABB761543673ABCF540CAC36927564F892FC148B436934AD38AD6D35C1EB8F3BB55F70BB02A'
DEFAULT TABLESPACE "USERS"
TEMPORARY TABLESPACE "TEMP"
PASSWORD EXPIRE
ACCOUNT LOCK;
SQL> GRANT "RESOURCE" TO "HR";
Grant succeeded.
SQL> GRANT CREATE SESSION TO "HR";
Grant succeeded.
SQL> GRANT ALTER SESSION TO "HR";
Grant succeeded.
SQL> GRANT UNLIMITED TABLESPACE TO "HR";
Grant succeeded.
SQL> GRANT CREATE SYNONYM TO "HR";
Grant succeeded.
SQL> GRANT CREATE VIEW TO "HR";
Grant succeeded.
SQL> GRANT CREATE SEQUENCE TO "HR";
Grant succeeded.
SQL> GRANT CREATE DATABASE LINK TO "HR";
Grant succeeded.
SQL> GRANT EXECUTE ON "SYS"."DBMS_STATS" TO "HR";
Grant succeeded.
SQL> ALTER USER "HR" DEFAULT ROLE ALL;
Grant succeeded.
- Invoke RMAN and connect to the target PDB:
export NLS_DATE_FORMAT='DD-MON-YY HH24:MI:SS'
rman target sys@xttpdb
RUN
{
ALLOCATE CHANNEL XPLATFORM_BKUP_DISK1 DEVICE TYPE DISK;
ALLOCATE CHANNEL XPLATFORM_BKUP_DISK2 DEVICE TYPE DISK;
RESTORE
ALL FOREIGN DATAFILES TO NEW
FROM BACKUPSET '/archive/xttlnux/XTTSUN_xplat_bs36_piece1_20201029_14ve6dm4_1_1.bkp'
BACKUPSET '/archive/xttlnux/XTTSUN_xplat_bs35_piece1_20201029_13ve6dm4_1_1.bkp'
DUMP FILE FROM BACKUPSET '/archive/xttlnux/transport_tblsp_hr_test_meta.dmp';
RELEASE CHANNEL XPLATFORM_BKUP_DISK1;
RELEASE CHANNEL XPLATFORM_BKUP_DISK2;
}
using target database control file instead of recovery catalog
allocated channel: XPLATFORM_BKUP_DISK1
channel XPLATFORM_BKUP_DISK1: SID=512 instance=xttlnux2 device type=DISK
allocated channel: XPLATFORM_BKUP_DISK2
channel XPLATFORM_BKUP_DISK2: SID=615 instance=xttlnux1 device type=DISK
Starting restore at 29-OCT-20
channel XPLATFORM_BKUP_DISK1: starting datafile backup set restore
channel XPLATFORM_BKUP_DISK1: specifying datafile(s) to restore from backup set
channel XPLATFORM_BKUP_DISK1: restoring all foreign files in backup piece
channel XPLATFORM_BKUP_DISK1: reading from backup piece /archive/xttlnux/XTTSUN_xplat_bs36_piece1_20201029_14ve6dm4_1_1.bkp
channel XPLATFORM_BKUP_DISK2: starting datafile backup set restore
channel XPLATFORM_BKUP_DISK2: specifying datafile(s) to restore from backup set
channel XPLATFORM_BKUP_DISK2: restoring all foreign files in backup piece
channel XPLATFORM_BKUP_DISK2: reading from backup piece /archive/xttlnux/XTTSUN_xplat_bs35_piece1_20201029_13ve6dm4_1_1.bkp
channel XPLATFORM_BKUP_DISK1: restoring foreign file 17 to +DATA/XTTLNUX/B2A8DA5A8E2A777EE0540010E05D13EA/DATAFILE/users.929.1055079821
channel XPLATFORM_BKUP_DISK2: restoring foreign file 18 to +DATA/XTTLNUX/B2A8DA5A8E2A777EE0540010E05D13EA/DATAFILE/hr_test.928.1055079877
channel XPLATFORM_BKUP_DISK1: foreign piece handle=/archive/xttlnux/XTTSUN_xplat_bs36_piece1_20201029_14ve6dm4_1_1.bkp
channel XPLATFORM_BKUP_DISK1: restored backup piece 1
channel XPLATFORM_BKUP_DISK1: restore complete, elapsed time: 00:00:02
channel XPLATFORM_BKUP_DISK2: foreign piece handle=/archive/xttlnux/XTTSUN_xplat_bs35_piece1_20201029_13ve6dm4_1_1.bkp
channel XPLATFORM_BKUP_DISK2: restored backup piece 1
channel XPLATFORM_BKUP_DISK2: restore complete, elapsed time: 00:00:26
channel XPLATFORM_BKUP_DISK1: starting datafile backup set restore
channel XPLATFORM_BKUP_DISK1: specifying datafile(s) to restore from backup set
channel XPLATFORM_BKUP_DISK1: restoring Data Pump dump file to /u01/app/oracle/product/12.2.0.1/dbhome_1/dbs/backup_tts_XTTLNUX_32652.dmp
channel XPLATFORM_BKUP_DISK1: reading from backup piece /archive/xttlnux/transport_tblsp_hr_test_meta.dmp
channel XPLATFORM_BKUP_DISK1: foreign piece handle=/archive/xttlnux/transport_tblsp_hr_test_meta.dmp
channel XPLATFORM_BKUP_DISK1: restored backup piece 1
channel XPLATFORM_BKUP_DISK1: restore complete, elapsed time: 00:00:00
Performing import of metadata...
IMPDP> Master table "SYS"."TSPITR_IMP_XTTLNUX_CFfw" successfully loaded/unloaded
IMPDP> Starting "SYS"."TSPITR_IMP_XTTLNUX_CFfw":
IMPDP> Processing object type TRANSPORTABLE_EXPORT/PLUGTS_BLK
IMPDP> Processing object type TRANSPORTABLE_EXPORT/TABLE
IMPDP> Processing object type TRANSPORTABLE_EXPORT/INDEX/INDEX
IMPDP> Processing object type TRANSPORTABLE_EXPORT/CONSTRAINT/CONSTRAINT
IMPDP> Processing object type TRANSPORTABLE_EXPORT/INDEX_STATISTICS
IMPDP> Processing object type TRANSPORTABLE_EXPORT/COMMENT
IMPDP> Processing object type TRANSPORTABLE_EXPORT/CONSTRAINT/REF_CONSTRAINT
IMPDP> Processing object type TRANSPORTABLE_EXPORT/TRIGGER
IMPDP> Processing object type TRANSPORTABLE_EXPORT/TABLE_STATISTICS
IMPDP> Processing object type TRANSPORTABLE_EXPORT/STATISTICS/MARKER
IMPDP> Processing object type TRANSPORTABLE_EXPORT/POST_INSTANCE/PLUGTS_BLK
IMPDP> ORA-39082: Object type TRIGGER:"HR"."SECURE_EMPLOYEES" created with compilation warnings
ORA-39082: Object type TRIGGER:"HR"."UPDATE_JOB_HISTORY" created with compilation warnings
IMPDP> Job "SYS"."TSPITR_IMP_XTTLNUX_CFfw" completed with 2 error(s) at Thu Oct 29 13:44:46 2020 elapsed 0 00:00:32
Import completed
Finished restore at 29-OCT-20
released channel: XPLATFORM_BKUP_DISK1
released channel: XPLATFORM_BKUP_DISK2
RMAN> exit
At this point, the tablespaces have been converted and plugged into the target PDB and all objects are ready for use!
Interesting Items of Note
Interestingly, after performing the above conversion and migration without any issues, and as I normally do, I started to poke around to see what “really” happened. When I did so I found something quite interesting. Upon looking at “v$datafile” I found that while RMAN did assign OMF filenames at restoration time, it assigned a totally different directory to those files than all of the other files in the PDB.
SQL> select file#, name from v$datafile;
FILE# NAME
---------- ----------------------------------------------------------------------------
29 +DATA/XTTLNUX/B2E8839B69346990E05302EC090A3057/DATAFILE/system.932.1055165099
30 +DATA/XTTLNUX/B2E8839B69346990E05302EC090A3057/DATAFILE/sysaux.927.1055165099
31 +DATA/XTTLNUX/B2E8839B69346990E05302EC090A3057/DATAFILE/undotbs1.931.1055165099
32 +DATA/XTTLNUX/B2E8839B69346990E05302EC090A3057/DATAFILE/undo_2.925.1055165403
33 +DATA/XTTLNUX/B2A8DA5A8E2A777EE0540010E05D13EA/DATAFILE/hr_test.919.1055165973
34 +DATA/XTTLNUX/B2A8DA5A8E2A777EE0540010E05D13EA/DATAFILE/users.922.1055166029
As you may have noticed, there are 2 uuids present in ASM for the same PDB, “B2A8DA5A8E2A777EE0540010E05D13EA” and “B2E8839B69346990E05302EC090A3057”. Upon looking at the source system, it appears that despite specifying “TO NEW” in my RMAN RUN block, it still carried over the uuid from the old system. Of course there is nothing wrong with this other than files not being in the same directory and potentially causing an administration problem, but if you would like to fix it, normal methods apply one of which is “alter database move datafile ….”. The results of which can be seen below:
SQL> alter database move datafile 33;
Database altered.
Elapsed: 00:00:08.40
SQL> alter database move datafile 34;
Database altered.
Elapsed: 00:00:00.15
SQL> select file#, name from v$datafile;
FILE# NAME
---------- -----------------------------------------------------------------------------
29 +DATA/XTTLNUX/B2E8839B69346990E05302EC090A3057/DATAFILE/system.932.1055165099
30 +DATA/XTTLNUX/B2E8839B69346990E05302EC090A3057/DATAFILE/sysaux.927.1055165099
31 +DATA/XTTLNUX/B2E8839B69346990E05302EC090A3057/DATAFILE/undotbs1.931.1055165099
32 +DATA/XTTLNUX/B2E8839B69346990E05302EC090A3057/DATAFILE/undo_2.925.1055165403
33 +DATA/XTTLNUX/B2E8839B69346990E05302EC090A3057/DATAFILE/hr_test.957.1055166369
34 +DATA/XTTLNUX/B2E8839B69346990E05302EC090A3057/DATAFILE/users.919.1055166403
6 rows selected.
As you can see, all of the files now reside within ASM under the same UUID and are also still OMF. Hopefully this will help you decide if this is an appropriate migration method to get you to PDB on a different platform!
